Specifications
O2 Range: 0.00 to 45.00 mg/L O2 (ppm)
% Saturation O2: 0.0 to 300.0% O2
Temperature Range: -5.0 to 55.0 °C (23.0 to 131.0 °F)
O2 resolution: 0.01 (ppm) mg/L
% Saturation O2 Resolution: 0.1%
Temperature Resolution: 0.1 °C / 0.1 °F
O2 Accuracy: ±1.5% Full Scale
% Saturation O2 Accuracy: ± 1.5% Full Scale (@20 °C / 68 °F)
Temperature Accuracy: ± 0.4 °C (±0.8 °F)
Calibration DO: Automatic single (offset MA9070) or dual point with slope in 100% saturated air
Calibration Temperature: 2 point at 0 and 50 °C (32.0 and 122.0 °F)
Altitude compensation: 0 to 4000 m (13,120')
Altitude Resolution: 100 m (328')
Salinity Compensation: 0 to 40g/L
Salinity Resolution: 1 g/L
Temperature Compensation: Automatic, 0.0 to 50.0 °C (32.0 to 122.0 °F)
Probe: MA840/2 polargraphic probe (included)
Membranes: 5 included with O-Rings (included)
Computer Interface: RS232/USB opto-isolated
Power Supply: 12 VDC (included)
Dimensions Meter: 230 x 160 x 95 mm (9.0 x 6.3 x 3.7 inches)
Weight: 0.9 kg (2.0 lbs.)
Environment: 0 to 50°C / 32 to 122°F; max RH 95%
